| Items | Specification | |
|---|---|---|
| Power supply | Rated supply voltage | Three-phase 340V-10% to 460V+10% |
| Phase options | Single-phase/three-phase 200V-10% to 240V+10% | |
| Frequency | 50~60Hz±5%, voltage imbalance rate <3% | |
| Output | Maximum output voltage | Same as the input supply voltage |
| Output current rating | 100% rated current continuous output | |
| Maximum overload | 150% heavy load (60s), 120% light load (60s) | |
| Control functions | Drive mode | V/F control (VVF); speed sensorless vector control (SVC) |
| Frequency range | 0.00~600.00Hz / 0.0 to 3000.0HZ | |
| Speed control accuracy | ±0.2% rated synchronous speed | |
| Starting torque | 150%/1Hz (VVF), 150%/0.25Hz (SVC) | |
| DC braking | Braking frequency: 0.01 to max; Time: 0 to 30S | |
| Protection | Functions | Short circuit, overcurrent, overvoltage, undervoltage, phase loss, overload, overheating, etc. |
